Product Features:
Time slot mode can be set: Switch the operating mode and target value according to different time slots
Zero reactive power operation: Supports "zero" reactive power operation function
Harmonic Control: Achieve harmonic current control below the 25th order
High harmonic detection: Capable of detecting high-order harmonics
Subsynchronous oscillation suppression: Effectively suppress subsynchronous oscillation
High and low pressure crossing: Capable of crossing high and low pressures
Multi machine parallel control: Powerful multi machine parallel collaborative operation
Improved modeling and simulation: Comprehensive system modeling and simulation support
| Rated Voltage | 6kV~66kV |
| Input Voltage | 0.9~1.1pu; Low voltage ride through 0pu(150ms), 0.2pu(625ms) |
| System Frequency | 50Hz/60Hz,Allow short-term fluctuations |
| Output Capacity | ±0.1Mvar~±200Mvar |
| Response Time | ＜5ms |
| Power Loss | ≤0.8% |
| Current Harmonics(THDi) | ≤3%(≥25% Rated Power) |
| Adjustable range of power factor | -1～+1 |
| Operation Mode | Constant device reactive power mode, constant assessment point reactive power mode, constant assessment point power factor mode, constant assessment point voltage mode, load compensation mode |
| Parallel Connection Method | Multi machine parallel network operation, multi bus comprehensive compensation, multi group FC comprehensive compensation control |
| Protection Function | Bus overvoltage, bus undervoltage, SVG overcurrent, drive failure, power unit overvoltage, overcurrent, overtemperature, and communication failure; Protection functions such as input interface protection, output interface protection, and system power supply abnormality protection |
| Fault Handling | Adopting redundant design |
| cooling Method | Air cooling/Water cooling |
| Protection Level | Indoor type IP30, outdoor type IP54 |
| Storage Temperature | -40℃～+70℃ |
| Operating Temperature | -40℃～+55℃ |
| Relative Humidity | Monthly average not exceeding 90% (25 ℃), no condensation |
| Altitude | ≤5000m |
| Communication Interface | Ethernet RS485,CAN,High speed fiber optic communication interface |
| Communication Protocol | MODBUS_RTU, Profibus, Power CDT91 protocol, IEC61850-103/104 |
| Seismic Intensity | Ⅷ degree |
| Pollution level | Ⅳ degree |
